Rosco Custom Gobos – Designed and Made to Your Specifications

View full details

Bring your brand or event to life with a custom gobo from Creative Film & Theatre Solutions (CFATS). We produce high-quality gobos for any projector — from small 10 mm units to large 300 mm fixtures.

Why Choose CFATS

Fast turnaround. Expert advice. Professional results.
Logos, monograms, wedding names, textures — whatever you need, we make the process easy from artwork to finished gobo.

Ideal For

Corporate branding
Weddings & events
Film, theatre & broadcast
Architectural & outdoor lighting

Quick, Reliable, Customised

Tight deadline? Complex design? We’ll help you choose the right material and turnaround so your gobo is perfect — and delivered on time.

Gobo Types & Materials

We supply gobos in:

Stainless steel – robust, cost-effective, ideal for bold designs•
Aluminium – lightweight, durable metal option suitable for simple, open designs where heat resistance and rigidity are required.
Black & white glass – excellent detail for logos and fine line work
Colour glass – spot or full colour for complex or photographic images

We will advise which material options suit your artwork and projector.

Artwork Requirements

Vector artwork (logos, text, line art)

Preferred: EPS, AI, PDF or SVG
Fonts must be converted to outlines
CMYK preferred (RGB also acceptable)

Pixel-based artwork (photos or gradients)

Minimum 2100 × 2100 px at 600 dpi
Best format: layered PSD
Also accepted: TIFF, JPG, PDF, AI, EPS
CMYK or RGB

Low-resolution or fine-detailed designs may require adjustment or redrawing; we’ll advise before production.

Turnaround Times

Turnaround times vary depending on a range of factors, including artwork approval, design complexity, material type, and the quantity required. Larger orders or more intricate artwork may require additional production time.

Both glass and stainless-steel gobos follow different manufacturing processes, so the timeframe will depend on your specific requirements and where your order sits in the current production cycle.

For an accurate turnaround estimate tailored to your project, please get in touch with your artwork, projector details, and required quantities. We’ll review everything and advise the most suitable production approach.

How to Order a Custom Gobo

To quote and supply a custom gobo correctly the first time, we need the following information:

Artwork – the design you want projected.
Projector details – make/model or gobo size; essential as sizes vary widely.
Deadline / event date – helps us prioritise and advise realistic options.

Send your artwork and details by email to sales@cfats.com.au and we’ll provide an accurate quote, timelines, advice and further information. You can also call us on 02 9906 6262 if you’d like to talk it through.

Alternatively, submit the form below and we’ll get in touch.

Ordering Process

Send us your details and artwork.
We provide an accurate quote with timelines, advice and guidance.
Once you proceed and payment is received, we prepare a design proof for your approval.
Proof is reviewed. Any amendments will be made and an updated proof will be provided for final approval.
Once approved, your gobo is manufactured and shipped.
Regular updates and tracking will be provided throughout the process.

Gobo Fixture Compatibility, Gobo Size and Artwork Guide

Rosco steel & glass custom gobos · AU & NZ

Gobo Size & Fixture Compatibility — Match Your Fixture (AU & NZ)

The practical chart to match any fixture to the right Rosco gobo. Find your spotlight, moving head or projector, read off the outside diameter and image area, then order a custom steel or glass gobo cut precisely to size. Built for lighting designers, theatres, venues, hire companies and installers across Australia & New Zealand.

See the size chart Order a custom gobo

Steel & glassAny fixtureCustom cut to size2,800+ patterns

A custom Rosco gobo projected onto a building façade

Why size matters

The right size projects cleanly and fits safely

🎯

Fits your fixture

Every gobo holder and wheel has a set diameter. Match it exactly and the gobo seats correctly, focuses cleanly and won't rattle, jam or overheat in the gate.

🔎

Sharp, full-frame image

The max image area is the largest artwork that projects without clipping. Design to it and your logo or pattern fills the beam edge to edge, in focus.

🛠️

Steel or glass

Steel for breakups and single-colour patterns; glass for logos, gradients, fine detail and full colour. We cut both to any diameter for almost any holder.

Steel vs glass

Which gobo material should you choose?

Both mount the same way and use the same size chart below — the difference is what they can reproduce. Pick the material to suit the artwork, then order it in the diameter your fixture needs.

⚙️

Steel (metal) gobos

Laser-cut single-layer patterns — the workhorse for texture and shape.

Breakups, foliage, windows, bar patterns
Simple single-colour logos and text
Toughest option, handles the most heat
Most economical for pattern work

🎨

Glass gobos

Photographic detail and full colour, printed and fired onto glass.

Multi-colour logos and brand marks
Gradients, halftones and photographic images
Fine detail steel can't hold together
Black & white, 1–3 colour or full colour

Not sure which suits your artwork? Send us the file and your fixture — we'll advise steel or glass and confirm the size before you order.

A Rosco custom glass gobo projecting detailed imagery in an architectural setting

How to use this chart

Four steps from fixture to finished gobo

Find your fixture brand and model. Jump to the brand section below (ETC, Chauvet, Selecon, Martin, Robe, Showtec, Neo Framer and more) and locate your exact model.
Note the outside diameter and image area. The outside diameter is the physical size of the gobo blank; the max image area is the largest artwork that projects cleanly.
Choose steel or glass. Steel for simple breakups and patterns; glass for logos, gradients, fine detail and full-colour artwork.
Order your Rosco custom gobo from CFATS. Order online below, or email your artwork and fixture details and we'll handle the rest.

Find your fixture

Jump to brand / fixture family

Click a brand to jump straight to its gobo size table.

Standard gobo sizes (lettered)

Many fixtures use "standard" letter sizes. Always confirm against your fixture manual, but these common sizes are a good starting point when specifying gobos.

Standard Size	Outside Diameter	Max Image Diameter	Typical Use / Notes
A Size	100 mm	75 mm	Larger profiles / many 1–2 kW fixtures, some Selecon & Robert Juliat
B Size	86 mm	64 mm	Common for ETC Source Four, many profile spots
D Size	53.3 mm	40 mm	Smaller projectors and scanners
E Size	37.5 mm	28 mm	Compact profile fixtures & smaller projectors
G Size	≈ 66 mm	≈ 45–48 mm	Some Clay Paky and specialty fixtures
J Size	38.8 mm	25 mm	Smaller projectors
M Size	66 mm	48 mm	Used in many compact profiles (e.g. some Showtec, ETC Jr)
T Size	46.05 mm	38 mm	Various compact fixtures
V Size	22.5 mm	≈ 17–22 mm	Very small scanners / moving heads

Measurements are approximate and may vary slightly between manufacturers. Always confirm with your fixture's documentation if you are unsure, or contact CFATS for help.

Gobo sizes by fixture make & model

The tables below list common fixtures used in theatres, events and installations across Australia and New Zealand. If your exact light isn't listed, CFATS can still manufacture the correct Rosco custom gobo — just tell us the make, model and gobo size.

ADJ (American DJ)

Make / Model	OD (Glass)	OD (Steel)	Max Image Area	Notes
ADJ Gobo Projector LED	26.8 mm	26.8 mm	24 mm	Small logo projector
ADJ Pro 150	88 mm	88 mm	38 mm	Large-format projector
ADJ Rotogobo	26 mm	26 mm	20 mm	Rotating gobo effect
ADJ Scrambler	37.5 mm	37.5 mm	28 mm	E-size style

Chauvet DJ — Gobo Projectors & Moving Heads

Make / Model	Outside Diameter	Max Image Area	Typical Gobo Size	Notes
Chauvet GoboZoom LED 2.0	28.6 mm	26 mm	Custom small glass/metal gobo	Compact LED gobo projector
Chauvet Gobo Zoom 2	≈ 37.3–37.5 mm	22 mm	E-Size style (E 37.5 / 22 mm)	High-powered custom gobo projector with zoom
Chauvet LFS-5	25–25.2 mm	19 mm	Small custom gobo	Profile-style LED projector
Chauvet Intimidator Spot 475ZX	25.7 mm	21 mm	Custom round gobo	250 W LED moving head, max thickness ≈ 1.3 mm

Clay Paky — Alpha / Stage / Miniscan

Model	OD (Glass)	OD (Steel)	Max Image Area	Wheel / Notes
Alpha Spot 575 – Rotating wheel	37.5 mm	37.5 mm	25.5 mm	Rotating gobos
Alpha Spot 575 – Effect wheel	28 mm	28 mm	25.5 mm	Effect wheel
Alpha Spot 1200 – Fixed wheel	31.5 mm	31.5 mm	25 mm	Static gobos
Alpha Spot 1200 – Rotating wheel	37.5 mm	37.5 mm	25.5 mm	Rotating gobos
Alpha Spot 1500 / Alpha Profile 1500 – Rotating	37.5 mm	37.5 mm	25 mm	Rotating gobos
Alpha Spot 1500 / Alpha Profile 1500 – Fixed	31.5 mm	31.5 mm	23 mm	Static gobos
Miniscan HPE	25.5 mm	25.5 mm	20 mm	Scanner
Stage Light 300	25.5 mm	25.5 mm	23 mm	Profile spot
Stage Zoom 1200 / Stage Scan 1200	51.8 mm	66 mm	48 mm	Larger G-size style gobos

Coemar

Model	OD (Glass)	OD (Steel)	Max Image Area
Coemar CF7	26 mm	26 mm	19 mm
Coemar Clubscan	32.9 mm	32.9 mm	28 mm
Coemar iSpot 150 / 575	32.9 mm	32.9 mm	≈ 26–28 mm
Coemar iSpot 1200	32.9 mm	32.9 mm	24 mm

ETC — Source Four Family

Model	Gobo Size	Outside Diameter	Max Image Area	Notes
Source Four – 5° / 10° / 19° / 26° / 36°	B Size	86 mm	64.5 mm	Standard B-size metal or glass
Source Four – 50°	A Size	100 mm	≈ 70 mm	Uses A-size for larger field
Source Four Jr	M Size	66 mm	49.5 mm	Compact profile, M-size gobos
Source Four Revolution (Profile head)	M Style	66 mm	48 mm	Motorised profile head

Futurelight & Servospot

Model	Outside Diameter	Max Image Area	Notes
Futurelight MH660 / Servospot 250	≈ 26.5 mm	≈ 23 mm	Rotating gobos
Futurelight MH840 / MH860	≈ 26.5 mm	≈ 23 mm	Spot moving heads
Futurelight PS/D-200 Promotion Scan	53.3 mm	40 mm	D-size pattern area

Gantom / Genie Logo Projectors

Model	Outside Diameter	Max Image Area	Notes
Gantom iQ (Darklight GT-GB1)	19 mm	15 mm	Ultra-compact IP65 logo projector
Genie Shiva 250 / 350	25.4 mm	18 mm	Small moving head / scanner
Genie Mojo Rotogobo	25 mm	18 mm	Rotating logo gobo unit

Griven

Model	Outside Diameter	Max Image Area
Gobo Clip / GoboStorm	53.3 mm	≈ 42 mm
ProMotion 1200 / 2000 (moving head)	53.3 mm	40 mm

High End Systems

Model	Outside Diameter	Max Image Area	Notes
Cyberlight	≈ 44 mm	≈ 36 mm	Scanner-style fixture
Intellabeam	≈ 29 mm	≈ 18–22 mm	Classic scanner
Show Gun	64.9 mm	53.3 mm	Large format effects head
Trackspot / Trackspot Bolt	25 mm	≈ 22 mm	Compact scanner
Studio Spot 250	25 mm	20 mm	Moving head spot
Studio Spot 575 / X-Spot	36.3 mm	31.5 mm	Medium moving head

iLED / Image / Opti

Model	Outside Diameter	Max Image Area
iLED LEDSpot 1000 / 2000 (rotating)	25.95 mm	19 mm
iLED LED Spot 2000 (fixed)	28.95 mm	22 mm
iLED LED Spot 4000	32.75 mm	24 mm
Opti K2 / K4	50 mm	≈ 35 mm usable
Opti Gobo Show F2	50 mm	≈ 35 mm usable

Martin — MAC & Mania Series

Model	Outside Diameter	Max Image Area	Notes
MAC 250 / 250+	22.5 mm	17 mm	Compact moving head
MAC 250 Krypton / 250 Entour	22.5 mm	17 mm	Same gobo size as MAC 250
MAC 350 Entour	27.8 mm	23 mm	Medium moving head
MAC 500 / 550 / 575 Krypton / 700	27.8 mm	23 mm	Common touring workhorses
MAC 2000 / MAC III / MAC Viper	37.5 mm	≈ 27–30 mm	Larger pattern area
Mania PR1 / Imagescan / Imager	53.3 mm	40 mm	D-size–style projector gobos
Mania SCX600 / SCX700	22.5 mm	17 mm	Scanner fixtures
MiniMAC Profile / Maestro	22.5–37.5 mm	≈ 17–30 mm	Compact MAC family

Ljusdesign Neo Framer (Narrow & Wide)

Neo Framer fixtures from Ljusdesign (often specified in galleries and museums) use an E-size gobo holder.

Model	Gobo Size	Outside Diameter	Notes
Neo Framer Narrow	E Size	37.5 mm	Uses an E-size gobo holder; suitable for soft breakups and textures
Neo Framer Wide	E Size	37.5 mm	Wide-angle profile with E-size gobos

Pearl River

Model	Outside Diameter	Max Image Area
Pilot 150 (new model)	26.9 mm	22 mm
Pilot 250	27.8 mm	23 mm
PR-XL250 / PR-XS250	22.5 mm	17 mm
PR-XL575 / PR-XL700	36.3 mm	31 mm

Prolite

Model	Gobo Size	Outside Diameter	Max Image Area
Prolite Metal Halide 150W Profile	B Size	86 mm	≈ 65 mm

Robe — ClubSpot / ColourSpot / Robin

Model	Outside Diameter	Max Image Area	Notes
Clubspot 150CT	22.5 mm	≈ 17–19 mm	Small club spot (contact CFATS to confirm image area)
Clubspot 160CT / 250CT / 300CT / 500CT	26.8 mm	22 mm	Club series spots
Spot 150XT / 160XT / 250XT	26.8 mm	≈ 22–22.5 mm	Compact moving heads
ColourSpot 170AT / 250AT / 575AT / 700AT	26.8 mm	22 mm	Very common Robe spot heads
ColourSpot 1200AT	≈ 37.5 mm	31 mm	Large format spot
ColourSpot 2500AT	37.5 mm	31.5 mm	High-power spot
Robin DLX / MMX / 600E Spot / 300 Plasma	26.8 mm	≈ 22–22.5 mm	Current Robin family spots

Robert Juliat

Model / Family	Gobo Size	Outside Diameter	Max Image Area
2.5k HMI Profiles	A Size	100 mm	≈ 58–75 mm (depending on optics)
D'Artagnan 900SNX 2500W	A Size	100 mm	≈ 58–75 mm

Selecon — Aureol / Accent / Pacific / Arena

Model	Gobo Size	Outside Diameter	Max Image Area
Aureol Beamshaper / Aureol	E Size	37.5 mm	28 mm
Accent (Architectural)	E Size (28 mm aperture)	37.5 mm	24 mm
Pacific 5.5–13° / 12–28° Zoom	M Size	66 mm	≈ 48–59 mm
Pacific 14–35° Zoom	B Size	86 mm	≈ 59–64 mm
Pacific 23–50° / Fixed beams / Arena range	A Size	100 mm	≈ 59 mm
Display Profile (12V / CDM)	E Size	37.5 mm	28 mm

SGM — Giotto, Victory & Galileo

Model	Outside Diameter	Max Image Area
Giotto Spot 250 / 400 (yoke)	28 mm (in 30 mm recess)	≈ 23–24 mm
Giotto Spot 1200	42.9 mm (in ring ≈ 49 mm)	40 mm
Victory 2	≈ 33 mm	30 mm

Showtec Performer Profile 150 Q6 / 700 Q6

Showtec Performer Profile fixtures use industry-standard M-size gobos via dedicated gobo holders.

Model	Gobo Size	Outside Diameter	Max Image Area	Notes
Showtec Performer Profile Zoom 150 Q6	M Size	66 mm (holder ~60 mm)	≈ 48 mm	150 W RGBACL profile, M-size metal or glass
Showtec Performer Profile 600 / 650 / 700 Q6	M Size	66 mm	≈ 48 mm	Performer Profile gobo holder compatible with M-size gobos

Strand

Model / Family	Gobo Size	Notes
Cadenza / Arena Zoomspot	A Size	Large theatre profiles
Cantata / Prelude / P23	B Size	Common Strand profiles
Optique (with holder)	M Size	Uses M-size style gobos

Studio Due — Shark Series

Model	Outside Diameter	Max Image Area
Shark 150	24 mm	19 mm
Shark 250 (Italian version)	23.7 mm	19 mm
Shark 250 (Chinese version)	27.3 mm	19 mm

This guide focuses on the most common fixtures we see in Australia & New Zealand. There are many more legacy and niche fixtures on the market; if yours isn't listed, CFATS can still supply the correct Rosco custom gobo once we confirm your exact size.

Order online

Order a Rosco custom gobo cut to size

Know your size from the chart above? Order directly. Choose your gobo size at checkout, and send your artwork after ordering — or email it first and we'll confirm everything before you buy.

Steel · patterns & single-colour logos

Rosco Custom Steel Gobo

Laser-cut steel for breakups, textures, patterns and simple logos. Cut to A, B, M, Image Spot or a fully custom diameter to fit your fixture.

View product →

Glass · full colour & fine detail

Rosco Custom Glass Gobo

Photographic detail, gradients and full colour fired onto glass. Choose your size and colour count — black & white through to multi-coloured.

View product →

Not sure of your size, or need a diameter that isn't listed? Email sales@cfats.com.au or call 02 9906 6262 and we'll spec it for you.

Artwork guidelines

Send artwork that projects sharply

To achieve the sharpest projection, vector artwork is best. If you only have a basic logo or an unusual file type, just send it through — we'll review it and advise the best way to proceed.

📁

File formats

Preferred (vector): AI, EPS, PDF.
Also accepted: PSD, TIFF, PNG, JPG — high-resolution only, suitable for full-colour or photographic gobos.

📐

Resolution & size

Metal gobos: min 150 dpi, 700 × 700 px or larger
Glass gobos: min 300 dpi for clean, sharp projection
Vector files: no resolution limits — scale cleanly at any size

✨

A quick tip

Higher-quality artwork always produces a sharper projection. Bold shapes and clean lines read best; very fine hairlines can drop out at small sizes, especially in steel.

Gobos in the wild

What a well-sized custom gobo can do

Real Rosco projects where custom gobos shaped the space. Courtesy of Rosco Spectrum.

Poetic text projected by Rosco Image Spots across the interior of Metz Cathedral

A gobo projection picking out architectural detail inside Metz Cathedral

Case study · Metz Cathedral, France — 800th anniversary

Custom glass gobos guide a spiritual journey through a cathedral

For the 800th anniversary of Metz Cathedral, lighting designers Quartiers Lumières and graphic studio Nouvelle Étiquette used Rosco Image Spots with custom glass gobos to project poetic text — in a bespoke medieval-inspired typeface — across the walls, floors and columns. Each projection was sized to sit precisely within the architecture and programmed to fade slowly in and out, inviting visitors to look up and notice a detail they'd otherwise miss. It's a clear demonstration of why image area matters: the artwork was cut to land exactly where it needed to.

"The Image Spot projectors, sized to suit the project and DMX controllable, project perfectly sized images to fit in with the architectural details and warm lighting."Lionel Bessières — Lighting Designer, Quartiers Lumières

Read it on Rosco Spectrum →

Courtesy of Rosco Spectrum

Case study · Varberg, Sweden — "The Enchanted City" festival

Custom gobos turn building façades into a festival of light

For the Rys och Mys ("Thrill and Chill") festival, lighting designer Johan Röklander of TRS Consulting used Rosco Image Spot HO projectors to throw stars, spiderwebs, hearts and children's own artwork across the façades of Varberg's buildings and fortress. Custom glass gobos carried the artwork; the higher-output fixtures let the team project from greater distances and onto more difficult, textured brick surfaces while keeping the colour saturated and the images crisp.

"The extra strength of the light allows us to project deeper colors on more difficult surfaces… the colors would not have been so clear."Johan Röklander — Lighting Designer, TRS Consulting

Read it on Rosco Spectrum →

Courtesy of Rosco Spectrum

Custom gobo projections on building façades at the Varberg light festival

Rosco custom glass gobos made from children's artwork

Gobo FAQs

Sizing & ordering questions

How do I find the right gobo size for my fixture?

Find your fixture in the tables above and read off the outside diameter (the physical blank size) and the max image area (the largest artwork that projects cleanly). If your model isn't listed, send us the make and model — or a photo of the gobo holder — and we'll confirm the size.

Steel or glass — which should I order?

Use steel for breakups, textures, patterns and simple single-colour logos. Use glass for multi-colour logos, gradients, photographic detail and fine artwork that steel can't hold together. Both come in the same range of sizes.

My exact fixture isn't in the chart. Can you still help?

Yes. This guide covers the most common fixtures in Australia & New Zealand, but CFATS can manufacture a Rosco custom gobo to almost any diameter, in steel or glass, for nearly any holder or wheel. Just tell us the make and model, or send a photo of the holder or an existing gobo.

What artwork should I supply?

Vector files (AI, EPS, PDF) are best and scale cleanly. We also accept high-resolution PSD, TIFF, PNG or JPG for full-colour or photographic glass gobos — 300 dpi for glass, 150 dpi (700 × 700 px or larger) for metal.

Do you deliver across Australia and New Zealand?

Yes. CFATS is the exclusive Rosco agent for Australia & New Zealand and supplies custom gobos to theatres, venues, hire companies, AV integrators and installers throughout both countries.

Need a gobo rotator or holder? Find the exact holder for your projector with our fixture finder, and compare the Rosco SimpleSpin, RevoPRO and Film/FX rotators. Rotators & holders — find yours →

Get the size right the first time.

Match your fixture above and order a Rosco custom gobo cut to size — or tell us the make and model and we'll confirm the size, material and artwork for you.

Order a custom gobo Ask a gobo specialist

Talk to a gobo specialist at CFATS

We support lighting professionals, theatres, venues, TV, film and installers across Australia & New Zealand. Exclusive Rosco agent for Australia & New Zealand.

Email us Call 02 9906 6262

← Back to Gobo Hub
